Product Description:
Stainless steel pipe is widely used in piping systems for conveying
fluids or gases. It is made from an alloy that contains nickel and
chromium, which gives it corrosion-resistant properties. Moreover,
stainless steel pipe has low maintenance because it is highly
resistant to oxidation, even at high temperature and chemical
environments. Additionally, food and beverage industries as well as
pharmaceuticals prefer stainless steel pipe because of its low
contamination when they are washed and sanitized.
This type of pipe can be manufactured using several processes,
either welding or extrusion. The welding process requires the
shaping of steel into a pipe shape and joining its seams. The
extrusion process involves heat treatment combined with piercing of
a steel rod to be formed into a pipe. The terms “pipe” and “tube”
are often confused, but they should be distinguished. Steel pipes
are connected according to internal diameter (ID), whereas steel
tubes are measured by external diameter (OD) and the wall
thickness. Pipes are made to transfer fluids or gases, while tubes
are made for manufacturing components with a definite structure.
Features:
- Product Name: Stainless Steel Pipe Tube
- Thickness: Customized
- Outer Diameter: 6mm-2500mm
- Tolerance: Customized
- Standard: API 5L, API 5CT, ASTM 53, EN10217, DIN 2458. IS 3589, JIS
G3452, BS1387
Technical Parameters:
| Product | Electric Resistance Welded Steel Pipe |
| Usage | Used for low-pressure liquid delivery, such as water, gas, and oil.
Oil drilling and machinery manufacturing, etc. |
| Standard | API 5L, API 5CT, ASTM 53, EN10217, DIN 2458. IS 3589, JIS G3452,
BS1387 |
| Out Diameter | 21.3mm -660.4mm |
| Wall Thickness | 1.5mm-25.4mm |
| Length | 0.3m – 18m |
| Steel Grade |
| API 5L | GR B, X42,X46, X56, X60,X65,X70,X80 |
| ASTM A53 | GR A, GR B, GR C |
| EN | S275, S275JR, S355JRH, S355J2H |
| GB | Q195, Q215, Q235, Q345, L175, L210, L245, L320, L360- L555 |
| Surface Treatment | Fusion bond Epoxy coating, Coal Tar Epoxy, 3PE, Vanish Coating,
Bitumen Coating, Black painting or as per customer’s requirement |
Applications:
TALAT brand stainless steel pipe tube is widely used in various
scenes and application scenarios. It is known for its excellent
tolerance, high standard, and various shapes and materials. It is
made of 304, 304L, 309S, 310S, 316, 316Ti, 317, 317L, 321, 347,
347H, 304N, 316L, 316N, 201, 202 and has an outer diameter range
from 21.3mm to 660.4mm. It is mainly used in electric resistance
welded pipes, ASTM stainless steel tube, stainless steel seamless
tube and TIG welded stainless steel pipe. It is very durable and
corrosion resistant, and is widely used in chemical, petroleum,
medical, food, light industry, machinery, instrument, and other
industrial sectors.
Customization:
Customized Stainless Steel Pipe Tube
- Brand Name: TALAT
- Place of Origin: China
- Product: Electric Resistance Welded Steel Pipe
- Thickness: Customized
- Outer Diameter: 6mm-2500mm
- Material: 304, 304L, 309S, 310S, 316, 316Ti, 317, 317L, 321, 347,
347H, 304N, 316L, 316N, 201, 202
- Surface Treatment: Fusion Bond Epoxy Coating, Coal Tar Epoxy, 3PE,
Vanish Coating, Bitumen Coating, Black Painting Or As Per
Customer’s Requirement
- Specialized in Stainless Steel Tube Pipe, stainless steel hollow
tube, Stainless Steel Seamless Tube, Stainless Steel Welded Tube
Packing and Shipping:
1. Standard sea-worthy export packing,
2. plastic cap with both ends
3. steel strip bundled package, waterproof cloth packaging
4. wooden case,wooden pallet package
5. container or bulk (According to customer's requirement)
6. wooden pallets with plastics protection.
7. 15-20MT can be loaded into 20 ftcontainer and 25-27MT can be
loaded into 40 ft container.
8. For 20 ft container the max length is 5.8m, for 40 ft container
the max length is 11.8m.
9. The other packing can be made based on the customer requirement.
